5.1.1. Full Example

1. my-cool-object.h


   #pragma once

   /* Include the GObject library */
   #include <glib-object.h>

   /* We need this for the GIcon object interface type, which we'll use later. See
      https://docs.gtk.org/gio/iface.Icon.html */
   #include <gio/gio.h>

   /* This macro sets up the necessary inclusion syntax for C declarations if you
      are using this header from C++ */
   G_BEGIN_DECLS

   /* Define a macro for retrieving the GType for this object class. GType is
      typedef'd to gsize, or basically size_t. This number will serve as the ID for
      your class in the type system. */
   #define MY_TYPE_COOL_OBJECT (my_cool_object_get_type ())

   /* Use this macro to declare your type. The arg meanings are as follows:

      MyCoolObject   -> the full pascal case C type name
      my_cool_object -> the same as above except snake case
      MY             -> the macro-style (snake case but capitalized) prefix; as
                        an example, for GtkFileDialog, this would be GTK
      COOL_OBJECT    -> the macro-style name; as an example, for GtkFileDialog,
                        this would be FILE_DIALOG
      GObject        -> the C type of the parent class */
   G_DECLARE_FINAL_TYPE (MyCoolObject, my_cool_object, MY, COOL_OBJECT, GObject)

   /* Constructor function */
   MyCoolObject *my_cool_object_new (void);

   /* We'll make the class MyCoolObject have two properties, a boolean
      "is-really-cool" and an object "icon" of type GIcon. Properties are cool
      because they give you a ton of tools for synchronizing data across your
      program automatically. Here we declare setters and getters for these
      properties */
   void     my_cool_object_set_is_really_cool (MyCoolObject *self, gboolean is_really_cool);
   gboolean my_cool_object_get_is_really_cool (MyCoolObject *self);

   void   my_cool_object_set_icon (MyCoolObject *self, GIcon *icon);
   GIcon *my_cool_object_get_icon (MyCoolObject *self);

   /* Let's also set up a regular method for this class. Since this function will
      return a dynamically allocated string, it's best practice to use "dup"
      (duplicate) instead of "get" in the name */
   char *my_cool_object_dup_description (MyCoolObject *self);

   G_END_DECLS


2. my-cool-object.c


   /**
    * MyCoolObject:
    *
    * MyCoolObject serves these purposes...
    */

   /* This define should come before any inclusions. It will give a domain to the
      GLib logging functions, which is useful for debugging */
   #define G_LOG_DOMAIN "MyCoolObject"

   /* Include our header */
   #include "my-cool-object.h"

   /* The backing struct for our class definition */
   struct _MyCoolObject
   {
     /* parent_instance MUST be the first field, and it MUST be an instance of the
        parent class of MyCoolObject, which is GObject */
     GObject parent_instance;

     /* Storage for our properties */
     gboolean is_really_cool;
     GIcon   *icon;
   };

   /* Use this macro to define the type, in a similar manner to how we declared it

      MyCoolObject   -> the full pascal case C type name
      my_cool_object -> the same as above except snake case
      G_TYPE_OBJECT  -> the GType of the parent class */
   G_DEFINE_FINAL_TYPE (MyCoolObject, my_cool_object, G_TYPE_OBJECT)

   /* These enums will be used to index our property specifications, defined after
      this. PROP_0 is equal to 0 and should not be used. LAST_PROP is only used to
      know how many properties we have. */
   enum
   {
     PROP_0,

     PROP_IS_REALLY_COOL,
     PROP_ICON,

     LAST_PROP
   };

   /* We'll populate this in my_cool_object_class_init () */
   static GParamSpec *props[LAST_PROP] = { 0 };

   /* This virtual function is called on the object when its last reference count
      is dropped and it is about to be destroyed. We should release our resources
      here */
   static void
   my_cool_object_dispose (GObject *object)
   {
     /* The MY_COOL_OBJECT () function performs a type check on the object and
        returns NULL if the input object is not of type MyCoolObject */
     MyCoolObject *self = MY_COOL_OBJECT (object);

     /* The g_clear_pointer () macro is an easy way to call a destruction function
        on a pointer only if its location is non-NULL, and subsequently set that
        location to NULL to avoid use-after-free bugs.

        Since g_object_unref is used so commonly in conjunction with this macro,
        most codebases just use the wrapper macro g_clear_object (), which only
        takes 1 argument, the address of the pointer */
     g_clear_pointer (&self->icon, g_object_unref);

     /* Chain up to the parent class */
     G_OBJECT_CLASS (my_cool_object_parent_class)->dispose (object);
   }

   /* This virtual function is called when a property value is requested from our
      object. The prop_id will correspond to the enums we defined earlier. Our job
      here is to "fill" the GValue argument with the value we want to give. */
   static void
   my_cool_object_get_property (GObject    *object,
                                guint       prop_id,
                                GValue     *value,
                                GParamSpec *pspec)
   {
     MyCoolObject *self = MY_COOL_OBJECT (object);

     switch (prop_id)
       {
       case PROP_IS_REALLY_COOL:
         g_value_set_boolean (value, my_cool_object_get_is_really_cool (self));
         break;
       case PROP_ICON:
         g_value_set_object (value, my_cool_object_get_icon (self));
         break;
       default:
         G_OBJECT_WARN_INVALID_PROPERTY_ID (object, prop_id, pspec);
       }
   }

   /* This virtual function is called when one of our properties is requested to be
      swapped out with a new value. The prop_id will correspond to the enums we
      defined earlier. Our job here is to read the GValue argument's value and
      store it somehow. Notice that the GValue argument is marked const. */
   static void
   my_cool_object_set_property (GObject      *object,
                                guint         prop_id,
                                const GValue *value,
                                GParamSpec   *pspec)
   {
     MyCoolObject *self = MY_COOL_OBJECT (object);

     switch (prop_id)
       {
       case PROP_IS_REALLY_COOL:
         my_cool_object_set_is_really_cool (self, g_value_get_boolean (value));
         break;
       case PROP_ICON:
         my_cool_object_set_icon (self, g_value_get_object (value));
         break;
       default:
         G_OBJECT_WARN_INVALID_PROPERTY_ID (object, prop_id, pspec);
       }
   }

   /* This is the class initialization function. This will be called only one time
      for the duration of our program, when our type is initialized. You can make
      sure this function has been called for a type by calling
      g_type_ensure(TYPE). */
   static void
   my_cool_object_class_init (MyCoolObjectClass *klass)
   {
     GObjectClass *object_class = G_OBJECT_CLASS (klass);

     /* Set the vfuncs we are implementing */
     object_class->set_property = my_cool_object_set_property;
     object_class->get_property = my_cool_object_get_property;
     object_class->dispose      = my_cool_object_dispose;

     /* This is where we populate the property specifications. There are many
        variants of "g_param_spec_*" for different types. Take a look at
        <gobject/gparamspecs.h> for a full list of them and their arguments */
     props[PROP_IS_REALLY_COOL] =
       g_param_spec_boolean ("is-really-cool", /* The name of this property */
                             NULL, NULL,
                             FALSE, /* The default value of this property */
                             /* These flags allow you to specify special behavior
                                for the property. Use G_PARAM_READABLE and
                                G_PARAM_WRITABLE for a read-only or write-only
                                property respectively. G_PARAM_STATIC_STRINGS
                                allows for a slight performance boost by making
                                GObject aware of the fact that the strings we
                                passed to this constructor are not dynamically
                                allocated. G_PARAM_EXPLICIT_NOTIFY lets GObject
                                know that we will manually emit the "notify" signal
                                on the object when we want others to know that this
                                property has changed, either from a setter or some
                                other event. */
                             G_PARAM_READWRITE | G_PARAM_STATIC_STRINGS | G_PARAM_EXPLICIT_NOTIFY);

     props[PROP_ICON] =
       g_param_spec_object ("icon",
                            NULL, NULL,
                            G_TYPE_ICON,
                            G_PARAM_READWRITE | G_PARAM_STATIC_STRINGS | G_PARAM_EXPLICIT_NOTIFY);

     /* Install the properties on the object class */
     g_object_class_install_properties (object_class, LAST_PROP, props);
   }

   /* This function is called when a particular instance of MyCoolObject is
      created. This is where you should initialize any parts of the object that
      doesn't just need to be zeroed out (GObject does this automatically). This
      means initializing mutexes, allocating arrays, etc. */
   static void
   my_cool_object_init (MyCoolObject *self)
   {
     /* Nothing to do... */
   }

   /* It is conventional to define a small wrapper around g_object_new() for a
      GObject type */
   MyCoolObject *
   my_cool_object_new (void)
   {
     return g_object_new (MY_TYPE_COOL_OBJECT, NULL);
   }

   /* Setter for property "is-really-cool" */
   void
   my_cool_object_set_is_really_cool (MyCoolObject *self,
                                      gboolean is_really_cool){
     /* Verify the pointer argument */
     g_return_if_fail (MY_IS_COOL_OBJECT (self));

     /* This is a cute trick you can use to check the equality of booleans in C
        without fear of "trues" being any non-zero value, like if is_really_cool=1
        and self->is_really_cool=5 */
     if (!!is_really_cool == !!self->is_really_cool)
       return;

     self->is_really_cool = is_really_cool;

     /* Since this property has G_PARAM_EXPLICIT_NOTIFY, we MUST call this if we
        want to notify others that the property has changed */
     g_object_notify_by_pspec (G_OBJECT (self), props[PROP_IS_REALLY_COOL]);
   }

   /* Getter for property "is-really-cool" */
   gboolean
   my_cool_object_get_is_really_cool (MyCoolObject *self)
   {
     g_return_val_if_fail (MY_IS_COOL_OBJECT (self), FALSE);
     return self->is_really_cool;
   }

   /* Setter for property "icon" */
   void
   my_cool_object_set_icon (MyCoolObject *self,
                            GIcon *icon)
   {
     g_return_if_fail (MY_IS_COOL_OBJECT (self));

     if (icon == self->icon)
       return;

     g_clear_pointer (&self->icon, g_object_unref);
     if (icon != NULL)
       self->icon = g_object_ref (icon);

     g_object_notify_by_pspec (G_OBJECT (self), props[PROP_ICON]);
   }

   /* Getter for property "icon" */
   GIcon *
   my_cool_object_get_icon (MyCoolObject *self)
   {
     g_return_val_if_fail (MY_IS_COOL_OBJECT (self), NULL);
     return self->icon;
   }

   /* Implement our special method */
   char *
   my_cool_object_dup_description (MyCoolObject *self)
   {
     const char *cool_level_str = NULL;

     g_return_val_if_fail (MY_IS_COOL_OBJECT (self), NULL);

     if (self->is_really_cool)
       cool_level_str = "REALLY COOL";
     else
       cool_level_str = "cool ig";

     if (self->icon != NULL)
       {
         char *icon_str = NULL;
         char *tmp      = NULL;

         icon_str = g_icon_to_string (self->icon);
         if (icon_str == NULL)
           return g_strdup (cool_level_str);

         tmp = g_strdup_printf ("%s (the icon is %s)", cool_level_str, icon_str);
         g_free (icon_str);
         return tmp;
       }
     else
       return g_strdup (cool_level_str);
   }


5.1.2. Design Patterns
